Taiwan Grubu Döner Tablalar Divüzörler

SUA-210 CNC Divüzör

Tabla çapı Ø210 mm seçeneği sağlar.

Yüksek sertlik, ekstra geniş radyal ve eksenel yatak kullanır.

İsteğe bağlı olarak Ø170, Ø210 ve Ø250mm tabla çapına sahip modeller Japon yapımı sonsuz / sonsuz dişli ile donatılabilir.

Çok yüzeyli frenleme sağlayan özel labirent tipi çok parçalı disk fren ile donatılmıştır. Büyük alan tasarımı, kenetleme kuvvetini etkili bir şekilde artırır. Tablo yapısı, masa yüzeyinde kayma sorununu ortadan kaldırır.

SUAC-170 CNC Divüzör

Table diameter provides a choice of Ø170mm.

Employs high rigidity, extra large radial and axial bearing.

Upon request, models with table diameter of Ø170 and Ø210mm can be equipped with Japanese made worm/worm gear.

Equipped with special labyrinth type multi-piece disk brake that provides multi-surface braking. Big area design effectively increases clamping force. The table structure eliminates table surface floating problem.

SUH-400N CNC Divüzör

Table diameter provides a choice of Ø400mm.

Employs high rig idity, extra large radial and axial bearing.

Upon request, models with table diameter of Ø255, Ø320 and Ø400mm can be equipped with Japanese made worm/worm gear.

Designed with the new full circumference brake that features even braking force without run-out. High torque, easy lubrication as well as compact, rigid and enclosed structure ensure high cutting quality.

SUH-320N CNC Divüzör

Table diameter provides a choice of Ø320mm.

Employs high rig idity, extra large radial and axial bearing.

Upon request, models with table diameter of Ø255, Ø320 and Ø400mm can be equipped with Japanese made worm/worm gear.

Designed with the new full circumference brake that features even braking force without run-out. High torque, easy lubrication as well as compact, rigid and enclosed structure ensure high cutting quality.

SUH-255N CNC DİVÜZÖR

Table diameter provides a choice of Ø255mm.

Employs high rig idity, extra large radial and axial bearing.

Upon request, models with table diameter of Ø255, Ø320 and Ø400mm can be equipped with Japanese made worm/worm gear.

Designed with the new full circumference brake that features even braking force without run-out. High torque, easy lubrication as well as compact, rigid and enclosed structure ensure high cutting quality.

SUA-210B CNC DİVÜZÖR

Table diameter provides a choice of Ø210mm.

Employs high rigidity, extra large radial and axial bearing.

Upon request, models with table diameter of Ø170, Ø210 and Ø250mm can be equipped with Japanese made worm/worm gear.

Equipped with special labyrinth type multi-piece disk brake that provides multi-surface braking. Big area design effectively increases clamping force. The table structure eliminates table surface floating problem.

SUA-170B CNC DİVÜZÖR

Table diameter provides a choice of Ø170mm.

Employs high rigidity, extra large radial and axial bearing.

Upon request, models with table diameter of Ø170, Ø210 and Ø250mm can be equipped with Japanese made worm/worm gear.

Equipped with special labyrinth type multi-piece disk brake that provides multi-surface braking. Big area design effectively increases clamping force. The table structure eliminates table surface floating problem.
